60 mins Black Walnut Veneer Finished Single Leaf Solid Wood Fire Rated Doors For Hotel

Minimum Order Quantity : 1 set Price : Negotiable
Packaging Details : Inside Bubble Bags+ Strong Carton+Wooden Frame Delivery Time : 35 Days After Payment Received
Payment Terms : western union, moneygram,cash, l/c, t/t Supply Ability : 600 Sets per Day
Place of Origin: CHINA Brand Name: ZHONGWO
Certification: Intertek,BS,CCC Model Number: ZW-MM04

Detail Information

Material: Solid Wood, Infilling: Perlite Board/ Particle Board
Thickness Of Door Leaf: 45/50 Mm Frame: Metal Frame, Timber Frame
Fire Rating: 30/60/90mins Finish: Veneer With PU Paint; HPL; Melamine; PVC
Application: Hotel
High Light:

fire rated wood doors

,

wooden fire doors

Product Description

Wooden Fire Door

Zowor Fire Door has developed into leading fire doors manufacture all over China since its establishment in 1995. Nowadays her products ranges from wooden fire doors via steel fire doors to wooden interior doors. As far as wooden fire doors are concerned, Zowor Fire Door can finish about 1000 to 1200 doors every single day with most advanced production line in two factories of a total area of 30,000 sq. meters.



60 mins Black Walnut Veneer Finished Single Leaf Solid Wood Fire Rated Doors For Hotel 0



Characters of Zowor Wooden Fire Doors



Fire Rating: 30mins(0.5hour), 60mins(1 hour), 90mins(1.5hours)

Standard: BS476-part22:1987 for fire test; ISO 10140-2-2010 for Air Sound Insulation

Certificate: Certificate issued by Intertek for up 90mins fire rating.

Size Range: popular size of single doors is 3' wide by 7' high(915*2134mm), max. size is 4' wide by 8' high(1219*2400mm);

                       popular size of double doors is 6' wide by 7' high(1828*2134mm), max. size is 8' wide by 8' high(2400*2400mm).



• Thickness: 45mm for standard doors; 50mm for fire rated acoustic doors

Fire Door Core: Fireproof Perlite Board or Solid Particle Board(For acoustic doors also acoustic blankets)

Thickness of Core: 38mm

Temp Rise: 30 Minutes, 250 Degrees Maximum

 Material: Solid wood such as Pinewood, Beach, Mahogany, Cherry, Oak and Walnut

 Finish: Natural wood veneer or artificial veneer with PU painting; Laminate, HPL; PVC or Melamine

 Outlay: 3mm MDF or plywood on both sides

 Color: Customized to any RAL color

 Frame: Solid Wood Frames(Single or Double Rabbet) or Metal Frames(1.2mm Gal. Steel)

 Architrave: Solid Wood with finishes, popular sizes: 60*25mm, 70*25mm, 80*25mm or customized

 Wall Thickness: 150mm, 160mm, 180mm, 200mm, max. 300mm

 Weight: 60Kg per door





60 mins Black Walnut Veneer Finished Single Leaf Solid Wood Fire Rated Doors For Hotel 1





Package & Delivery



Standard package with PEP paper wrapped around the door, foam sheet on both sides, foamy corner protector at 4 edges and strong cartoons outside; the other is with wooden pallet or wooden box.

Package dimension is usually each 50mm more than door leaf sizes in width and height, and 15-20mm more in thickness.

Besides, standard package will make the door 2Kg heavier; And every wooden pallet weights itself 5kg, each wooden pallet can load max. 10 standard doors with frames.

As far as delivery is concerned, normally we export at Qingdao port, can also export at any port you want.

Product Size(W*H*T) Delivery Time GP20 GP40 HQ40
Wood Fire Door

915*2134mm

(3’ * 7’)

30 -45 days 234 506 566

1219*2438mm

(4’ * 8’)

114 228 362

Note: Quantity in container is calculated theoretically based on sizes of door leaf with package.
