Product Details:
|
|
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | ZHONGWO |
| Certification: | BS， WHI， UL, CCC |
| Model Number: | ZW-GM09 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | film on surface with cardboard carton outside |
| Delivery Time: | 30 days after reception of down payment |
| Payment Terms: | western union, moneygram,cash, l/c, t/t |
| Supply Ability: | 500 sets per day |
|
Detail Information |
|||
| Material: | Galvanized Steel | Finish: | Powder Coating, Wood Grain |
|---|---|---|---|
| Thickness Of Steel Sheet For Leaf: | 0.8 Mm,1.0 Mm,1.2 Mm | Thickness Of Steel Sheet For Frame: | 1.2 Mm,1.5 Mm,2.0 Mm |
| Thickness Of Door Leaf: | 45/55 Mm | Frame Depth: | 115/120 Mm |
| Size: | Max. 2400mm X2400 Mm | Color: | Customized |
| Fire Rating: | 30/60/90/120/180 Mins | Hardware: | International & Chinese Brand |
| High Light: | fire door insulation,steel fire door |
||
Product Description
Founded in 1995, Zhongwo has developed into a cooperative group with business scope ranging from fire doors, interior doors and WPC doors.
We have factory specially for WPC doors covering more than 100,000 square meters. With most advanced machines and most skillful technicians we can make up to 1000 sets fire doors each day.
Fire Rating
American Standard Steel Fire Door: Both of our single swing doors and pair doors are tested together with vision panels. Both of them can withstand up to 180mins against fire.
British Standard: Our steel fire door past through the fire test within 120mins in the lab. The BS steel fire door in test is also with vision panel.
Chinese Standard Steel Fire Door: we have 30mins, 60mins and 90mins steel fire doors for you choice.
Specification
| Product Name | Zhongwo Fire Rated Steel Doors |
| Fire Rating | 20/30/60/90/150/180mins |
| Standard |
NFPA,ANSI/UL 10B,UL10C BS476-22,CCC |
| Material of Door Leaf | Galvanized Steel Sheet |
| Material of Door Frame | Galvanized Steel Sheet |
| Thickness of Steel Sheet of Door Leaf | 20-18-16 Ga. (1.0/1.2/1.6 mm) |
| Thickness of Steel Sheet of Door Frame | 18-16-14 Ga. (1.2/1.6/2.0mm) |
| Thickness of Door Leaf |
US Standard Door: 40/45 mm BS Standard Door: 45/50/55/64 mm China Standard Door: 45/55 mm |
| Frame Depth | 115/120/130/160 mm |
| Weight | 35Kg/m2 |
| Size(Overall Frame Size) |
Single Door: Max. 1200 X 2400 mm Double Door: 2100 X 2400 mm or customized |
| Open Style | Swing Open |
| Infilling Material |
Standard: Fireproof Perlite Board; Magnesium Oxide Board Options: Honeycomb Paper, Mineral Wool, Polyethylene Foam |
| Surface Treatment | Powder Coating, Wood Grain or Customized |
| Color | Milk White, Matte Orange, Dark Gray, Cold Gray White or as Request |
| Fireproof Seal Strip |
FPJ-B-20X 2 FPJ-A-15X 2 Or Customized |
| Warranty | 2 years |
| Delivery Time | 45Days After Payment Received |
Hardware
For US standard UL listed hardware like fire door closer, fire hinges, fire locks. More options such as panic bars, electric-magnetic door holders and fire door selectors are also available.
For BS and China standard fire door we provide you with China CCC certified ironmongery such as fire rated door closers, fire rated hinges, locksets and other items as your request.
Remarks: If you don’t want ironmongery from us but only need us to punch hardware insert holes, please send us the specification and drawings of hardware you need, it will be best if you send us delivery samples.
Package
Our fire door and frame are individually packed.
Besides, we can also make wooden or steel pallet for you. Extra fees will be calculated then.
Transport
We provide you with shipping transport as our first choice for you. But if you need other transportation like trucks, railway and even aircraft, we can make related quotation for you.
