60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board

China 60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board supplier
60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board supplier 60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board supplier 60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board supplier 60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board supplier

Large Image :  60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board

Product Details:

Place of Origin: CHINA
Brand Name: ZHONGWO
Certification: ISO9001:2008, CCC
Model Number: ZW-GM02(B)

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Inside Bubble Bags+ Strong Carton+Wooden Frame
Delivery Time: 35 Days After Payment Received
Payment Terms: western union, moneygram,cash, l/c, t/t
Supply Ability: 600 Sets per Day
Contact Now
Detailed Product Description
Material: 304 Stainless Steel Fire Rating: 60/90 Min
Glass: Double Glazing Composite Fireproof Glass Size: Customized Size
Opening Degree: 90-180 Degrees Thickness Of Door Leaf: 45/55 Mm
Frame Depth: 112/120 Mm Thickness Of Steel Sheet For Door Frame: 1.2 Mm; 1.5 Mm
Thickness Of Steel Sheet For Door Leaf: 0.8 Mm; 1.0 Mm Application: Commercial Buildings, Shopping Mall, Supermarket Etc.

60/90 min Commercial 304 Stainless Steel Fire Rated Doors Patna With Fireproof Perlite Board

304 Stainless Steel Fire Rated Doors





Product Description



Zhongwo Stainless Steel Fire Door is made of high quality 304/201 stainless steel sheet with fireproof perlite board as infilling material,304/201 stainless steel contains elements of Nickel and Chromium which ensures the high corrosion resistance performance, thus Zhongwo stainless steel fire door provide you with longer operation life. Besides, It remains high yield strength and creep strength even at higher than 900℃,therefore it can effectively avoid explosion in case of fire.



All of our stainless steel fire doors are in pocession of CCC according to China national Standard GB12955:2008, which indicates the ensured quality of them.



Specification

Product Name Double Leaf 60/90 min Commercial 304 Stainless Steel Fire Rated Doors
Weight 25-28 Kg/m2
Certificate CCC, ISO9001:2008
Material of Door Leaf 201/304 Stainless Steel
Material of Door Frame 201/304 Stainless Steel
Thickness of Steel Sheet of Door Leaf 0.8 mm; 1.0 mm
Thickness of Steel Sheet of Door Frame 1.2 mm; 1.5 mm
Thickness of Door Leaf

90min: 55 mm

60min: 45 mm

Frame Depth

90min: 120 mm

60min: 112 mm

Size Standard: W1000X H2300(mm); 700X 2300(mm) or Customized As Your Request.
Open Style Swing Open
Infilling Material

90min: 53 mm Fireproof Perlite Board(400±40kg/m3)

60min: 43 mm Fireproof Perlite Board(300±30kg/m3)

Surface Treatment Finished
Color Silver
Glass

Standard:24mmX 200mmX 900mm;

32X 200mmX 900mm

Or Customized As Request

Fireproof Seal Strip

90min: FPJ-B-20X 2

60min: FPJ-A-15X 2

Or Customized

Warranty 2 years
Package Inside Bubble Bags+ Strong Carton+Wooden Frame
Delivery Time 35Days After Payment Received





Features

Item Double Leaf 60/90 min Commercial 304 Stainless Steel Fire Rated Doors
Top Quality and Eco-friendly& Healthy Infilling Material

All of our fireproof perlite boards must reach level A1 of the combustion performance standard according to GB8624-2006 and level ZA2 of toxicity standard according to GB/T20285-2006.

Besides, the density of our fireproof perlite board is in top quality, originally it reaches 472.6kg/m3, by drying treatment it still remains457.3kg/m3, which are both great higher than the standard of 420kg/m3.

High Anti-Explosion Performance It remains high yield strength and creep strength even at higher than 900℃,therefore it can effectively avoid explosion in case of fire.

Top Fire Insulation Performance

Average temperature rise of unexposed surface reaches 94.2℃, highest temperature rise at single point reaches 148.6℃, both are far away lower than the standard of not beyond 140℃ and 180℃. And the highest temperature point on door frame reaches 140.8℃, also much lower than the standard of not beyond 360℃.

Small Door Leaf Opening Force

Door leaf opening force of our stainless steel fire door is no more than 66N, which is much smaller than 80N according to GB12955-2008.





Packaging&Delivery

1. Matured packaging team consisting of professional and well-trained packaging staff with quality packaging materials.

2. Quick delivery within 35 days since transfer confirmed.
3. Reliable and professional logistics services which are all in long-term cooperation with us.
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
