Product Details:
|
|
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | ZHONGWO |
| Certification: | UL, CCC |
| Model Number: | ZW-GMM12 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | negotiable |
| Packaging Details: | Inside Bubble Bags+ Strong Carton+Wooden Frame |
| Delivery Time: | 35 Days After Payment Received |
| Payment Terms: | western union, moneygram,cash, l/c, t/t |
| Supply Ability: | 600 Sets per Day |
|
Detail Information |
|||
| Material: | Galvanized Steel | Fire Protection Time: | 1.5 Hours/1 Hour |
|---|---|---|---|
| Thickness Of Door Leaf: | 45/55 Mm | Thickness Of Door Frame: | 112/ 120 Mm |
| Infilling: | 43/ 53 Mm Fireproof Perlite Board | Type: | Swing Open |
| Size: | Customized Size | Color: | Customized |
| MOQ: | 1 Set | ||
| High Light: | Single Leaf Fireproof Entry Doors,Garage Entry Fire Door |
||
Product Description
Gal. Steel Red Single Leaf 6/ 9 Panel Fireproof Entry Doors For Residential Buildings
Steel Fireproof Entry Door
ZHongwo provide you with high quality 60/90 mins fire doors with anti-theft function. The Door leaf consists of 33/38 mm thick fireproof perlite board. And the size of our fire doors are all cunstomized as your request.
The fire door is equipped with advanced fingerprint identify system as secondary option otherwise the code system.
Material: The door frame adopts cold rolled galvanized steel plate with thickness of no less than 1.2mm.
The door leaf adopts cold rolled galvanized steel plate with thickness of no less than 0.8mm.
Hardware fitting backboard adopts ordinary steel plate with thickness of no less than 3.0mm.
Hardware fittings:The famous high-grade fire lock, door closer, fire prevention hinge, sequencer, latch etc.with characteristics that flexible, safe, reliable, and so on. They are approved by the national recognized inspection authority, and the performance meet GB12955-2008 appendix A, B, C, D.
Fire Resistance Rating(FRR):
Grade A: 1.5 Hours
Grade B: 1.0 Hour
Class A: also known as fully insulated door sets, it can meet the requirements of fire insulation and fire integrity at the same time within the prescribed time. The fire-resistance rating is 0.5h (Grade C), 1.0h (Grade B), and 1.5h (Grade A ) and 2.0h, 3.0h.
All of our fire doors are Class A fire doors.
Parameters
| Items |
Grade A Steel Insulated Fire Door |
Grade B Steel Insulated Fire Door |
Grade C Steel Insulated Fire Door |
| Fire Protection Time (H) | 1.5 | 1.0 | 0.5 |
| Code | A1.50 | A1.00 | A0.50 |
|
Thickness of Door Leaf (mm) |
55 | 45 | 45 |
|
Thickness of Door Frame (mm) |
120 | 112 | 112 |
| Thickness of Steel plate for Door Leaf (mm) | 0.8 | 0.8 | 0.8 |
| Thickness of Steel plate for Door Frame (mm) | 1.2 | 1.2 | 1.2 |
|
Thickness of Fire Glass (mm) |
32 | 24 | 24 |
| Fire Prevention Board | Available | N/A | N/A |
| Intumescent Seals Size(Width x Thickness)(mm) | 15x2 | 15x2 | 15x2 |
| Filled Material | Perlite Fireproof Board | Perlite Fireproof Board | Perlite Fireproof Board |
Package
Our fire door and frame are individually packed.
Besides, we can also make wooden or steel pallet for you. Extra fees will be calculated then.
Transport
We provide you with shipping transport as our first choice for you. But if you need other transportation like trucks, railway and even aircraft, we can make related quotation for you.
