UL 1.5 Hour Fire Rated Double Swing Fire Safety Door With Vision Lite & Panic Bar

Minimum Order Quantity : 1 set Price : Negotiable
Packaging Details : Inside Bubble Bags+ Strong Carton+Wooden Pallet Delivery Time : 45 Days After Payment Received
Payment Terms : western union, moneygram,cash, l/c, t/t Supply Ability : 600 Sets per Day
Place of Origin: CHINA Brand Name: ZHONGWO
Certification: BS, WHI, UL, CCC Model Number: ZW-SM09

Detail Information

Material: Galvanized Steel Fire Rating: 30/60/90
Finish: Prime Paint, Powder Coating, Wood Grain Thickness Of Door Leaf: 55 Mm
Thickness Of Steel Sheet For Door Leaf: 0.8 Mm Thickness Of Steel Sheet For Door Frame: 1.2 Mm
Infilling: Perlite Board; Honeycomb Paper, Mineral Core Glass: 3 Hours Composite Fireproof Insulated Glass
Opening Force: 66-68 N Opening Type: Swing Open
High Light:

fire proof door


fire protection door

Product Description

1.5 Hour Fire Rated Double Swing Fire Safety Door With Vision Lite & Panic Bar


Zhongwo UL 1.5 hour Steel Fire Door



Test and certification standard of Zhongwo BS steel fire doors are BS476-22:1987 and EN1634-1:2008. Fire rating of our doors can be FD30, FD60, FD90 and up to 120 mins.





As far as the dimension is concerned, we mean the overall structural opening sizes here. So please confirm whether your order is only about door leaf sizes or about overall sizes of leaf & frame.

Single Swing:1200(W) X 2400(H)mm

Double swing:2100(W) X 2400(H)mm




Standard Surface Treatment: Powder Coating

Options: Prime Painting and Heat Transfer Printing.


Color of doors decides on color of plastic powders.

Most popular color of plastic powders by us are as following:

PBG1001(Pure White), B1068(Beige), PS2328(Gray White), PS2869-2(Dark Gray), PS6018-5(Frosted Orange), PS7046WT(High Light Gray)


UL 1.5 Hour Fire Rated Double Swing Fire Safety Door With Vision Lite & Panic Bar 0


Hardware & Accessories


Hardware Fire Lock

Mortise Lock

Type: ROCK6072N

Lock Case Size:: 85 x 165 x 13 mm;

Backset: 60 mm;

Latch Throw: 10 mm;

  Fire Hinges

Steel Hinge

Size: 4.5 X 4.0 X 3.0 mm

Quantity: 3 for each leaf

  Door Closer Type: CA93-4CIII(Rock1800)
  Flush Bolt YB054, 8”
Fireproof Sealant Model 1: FPJ-B-25X2mm All around door edges.
Model 2: FPJ-B-20X2mm Under the astragal on push side.



Fire proof adhesive, applied at a rate of 0.4 ± 10% kg/m2.

Application: between steel face and perlite core on unexposed side.


Structure Description


Zhongwo BS steel fire doors consist of steel door leaves and steel frames. Door leaf structure can be split into 43mm thick magnesium oxide fire door core board, 5mm thick fireproof board and 0.8mm galvanized steel face sheets on both sides. Between fireproof board and fire door core board we brush fireproof glues, so does it between door core board and gal. Steel sheet. Thickness of door leaf is 55mm. Moreover there is also one astragal made from 0.8mm gal. Steel to cover the gap between door leaf and door frame. On the inside of astragal we also paste smoke intumescent to prevent spread of smoke and flame. The size of astragal is 25X2mm on the active leaf and 40X10mm on the inactive leaf of double doors.


Door frame is knock-down frame made of 1.2mm thick galvanized steel sheet. The frame by us is divided into 4 parts for standard doors, but for fire exit doors only into 3 parts without bottom thresholds. Frame depth is about 105mm. And the frame is normally installed in masonry wall. In order to keep its decoration performance we weld lock covers on the lock side of frame which makes the whole doorsets more beautiful and harmonious.


Besides, we weld 3mm thick gal. Steel plate as reinforcement and stiffener on hinges, locks, bolts and closer sides inside of both door leaf and frame. We also equip connectors with knock-down frame to ensure the stability and sturdy performance of frames. Connectors will be made of 0.8mm gal. Steel sheet.


Vision Panels


We manufacture also BS steel fire doors with vision panels. All of vision panels are made from heat insulated fireproof glass. As standard the size of vision panels by us is 203.2 X 608.6 X 32mm. To make sure the vision panel can be installed in the door leaf firmly, we add one steel skeleton specially around the vision holes which is made from 1.5mm thick gal. Steel sheet. As glass strip we use 0.8mm thick gal. Steel sheet.




Standard Package:

Door Leaf: one layer perlite cotton + one or two layers strong carton + foam board around 4 edges.

Door Frame: Band them together with tapes, cover around them with perlite cotton, protect them inside foam boards and at last load them into strong cartons.



We also make wooden pallet for you to pack the doors and frames with more security. But this may mean more package fees than standard choice.




Delivery time by us is normally 45 days after we receive your deposit. But we can certainly adjust the lead time according to evaluation of our technicians about difficulty rating, order quantity, and other factors.





Although the installation of our doors is so easy that any one can just make a DIY, we found our own professional installation team to make sure the last step of our service for us perfect.


UL 1.5 Hour Fire Rated Double Swing Fire Safety Door With Vision Lite & Panic Bar 1
