Single Swing Light Gray Color Powder Coated Fire Safety Door For Commercial Basement

Contact Now

Single Swing Light Gray Color Powder Coated Fire Safety Door For Commercial Basement

Minimum Order Quantity :	1 set	Price :	negotiable
Packaging Details :	PEP Paper on both sides+ Foam Channel Around 4 Edges and Corners + Foam Plate on both sides on PEP Paper + Strong Carton	Delivery Time :	30 days after reception of down payment
Payment Terms :	western union, moneygram,cash, l/c, t/t	Supply Ability :	1000 sets per day

Place of Origin:	CHINA	Brand Name:	ZHONGWO
Certification:	BS， WHI， UL, CCC	Model Number:	ZW-SM10

Detail Information
Fire Rating:	30/60/90 Mins	Finish:	Powder Coating, Wood Grain
Material:	Gal. Steel, Stainless Steel	Thickness Of Door Leaf:	45/55 Mm
Frame Depth:	115/120 Mm	Size:	Customized Size
Color:	Customized	Thickness Of Door Leaf Face Panel:	0.8mm /1.2mm
Thickness Of Doof Frame Face Panel:	1.2mm /1.8 Mm	Hardware:	UL Listed Hardware
High Light:	fire proof door , fire protection door

Product Description

Single Swing Light Gray Color Powder Coated Fire Safety Door For Commercial Basement

Fire Rated Glass Door With Steel Frame

Product Description

Inlaid with fire -proof expansion sealing pieces, the door frame is made of high quality galvanized steel strip, which is one-time rolled and formed through the special production line, without impact sound when closing.

Material: The door frame adopts cold rolled galvanized steel plate with thickness of no less than 1.2mm.
The door leaf adopts cold rolled galvanized steel plate with thickness of no less than 0.8mm.
Hardware fitting backboard adopts ordinary steel plate with thickness of no less than 3.0mm.

Hardware fittings:The famous high-grade fire lock, door closer, fire prevention hinge, sequencer, latch etc.with characteristics that flexible, safe, reliable, and so on. They are approved by the national recognized inspection authority, and the performance meet GB12955-2008 appendix A, B, C, D.

The Maximum Opening size is 2100(W)*2300(H) (mm)

Fire Resistance Rating(FRR):

Grade A: 1.5 Hours

Grade B: 1.0 Hour

Grade C: 0.5 Hour

Fire Resistance Rating Classification

Name	Fire Resistance Performance		Code
Fully Heat Insulated Doorsets(Class A)	Fire Insulation ≥0.50h Fire Integrity ≥0.50h		A0.50 (Grade C)
	Fire Insulation ≥1.00h Fire Integrity ≥1.00h		A1.00 (Grade B)
	Fire Insulation ≥1.50h Fire Integrity ≥1.50h		A1.50 (Grade A)
	Fire Insulation ≥2.00h Fire Integrity ≥2.00h		A2.00
	Fire Insulation ≥3.00h Fire Integrity ≥3.00h		A3.00
Partially Heat Insulated Doorsets(Class B)	Fire Insulation ≥0.50h	Fire Integrity ≥1.00h	B1.00
		Fire Integrity ≥1.50h	B1.50
		Fire Integrity ≥2.00h	B2.00
		Fire Integrity ≥3.00h	B3.00
No Heat Insulated Doorsets(Class C)	Fire Integrity ≥1.00h		C1.00
	Fire Integrity ≥1.50h		C1.50
	Fire Integrity ≥2.00h		C2.00
	Fire Integrity ≥3.00h		C3.00

Technical Parameters

Items	Grade A Steel Insulated Fire Door
Fire Protection Time (H)	1.5
Code	A1.50
Thickness of Door Leaf (mm)	55
Thickness of Door Frame (mm)	120
Thickness of Steel plate for Door Leaf (mm)	0.8
Thickness of Steel plate for Door Frame (mm)	1.2
Fire Prevention Board	Available
Filled Material	Perlite Fireproof Board
Door Leaf	2
Fire Closer	2
Fire Sequence	1

Application

Large-scale shopping malls, high-grade office buildings, top-three hospitals, office buildings, schools, hotels, libraries, museums, business centers and other high-rise buildings and fire exit in public places
