UL Listed Gal. Steel 1 Hour Commercial Fire Rated Doors With Vision Panel

Product Details:
Place of Origin: CHINA
Brand Name: ZHONGWO
Certification: BS, WHI, UL, CCC
Model Number: ZW-GM0403
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Bubble Bags Inside with Wooden Frame Outside
Delivery Time: 35 Days After Payment Received
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 600 Sets Per Day

Detail Information

Product Name: UL Listed Gal. Steel 1 Hour Commercial Fire Rated Doors With Vision Panel Material: Galvanized Steel
Fire Rating: 30/60/90 Mins Surface Treatment: Powder Coating/ Wood Grain
Thickness Of Door Leaf: 40/45/55 Mm Frame Depth: 90/112/120 Mm
Infilling: Fireproof Perlite Board Application: Commercial&Residential Buildings
Opening Degree: 90-180 Degrees Highest Temperature Rise: 148.6 ℃
High Light:

steel fire door


fire rated interior doors

Product Description

UL Listed Gal. Steel 1 Hour Commercial Fire Rated Doors With Vision Panel

 Steel Insulated Fire Door



Product Description


In production of Zhongwo steel insulated fire door we introduce advanced heat transfer printing and powder coating process, namely we paste one kind of transfer printing paper which occupies the color and texture of walnut onto the galvanized steel sheet which is originally very rigid and not natural, with thermal treatment we print the character of walnut paper into steel sheet. Thus the originally rigid steel sheet looks full of decoration. This is kind of steel fire door can match and integrate into the decorative style of buildings, so that the tone of entire room or house looks very harmonious and balanced.


UL Listed Gal. Steel 1 Hour Commercial Fire Rated Doors With Vision Panel 0




Product Name Steel Fire Door
Fire Rating 30 min/60 min/ 90min
Certificate CCC, ISO9001:2008; UL; BS
Material of Door Leaf Galvanized Steel Sheet
Material of Door Frame Galvanized Steel Sheet
Thickness of Steel Sheet of Door Leaf 0.8 mm
Thickness of Steel Sheet of Door Frame 1.2 mm
Thickness of Door Leaf

90min: 55 mm

60min: 45 mm

30min:40 mm

Frame Depth

90min: 120 mm

60min: 112 mm

30min: 90 mm

Open Style Swing Open
Infilling Material

90min: 53 mm Fireproof Perlite Board(400±40kg/m3)

60min: 43 mm Fireproof Perlite Board(300±30kg/m3)

30min: 38 mm Fireproof Perlite Board(300±30kg/m3

Surface Treatment

Heat Transfer Printing

Color RAL Color

Single Open: 24mmX 350mmX 600mm

Double Open: 32mmX 350mmX 600mm

Or customized As Request

Fireproof Seal Strip

90min: FPJ-B-20X 2

60min: FPJ-A-15X 2

30min: FPJ-A-15X 2

Or Customized

Warranty 2 years
Package Inside Bubble Bags with Outside Wooden Frame
Delivery Time 35Days After Payment Received


Product Advantage


Item Walnut Heat Transfer Printing Steel Fire Door
Eco-friendly& Healthy Infilling Material All of our fireproof perlite board must reach level A1 of the combustion performance standard according to GB8624-2006 and level ZA2 of toxicity standard according to GB/T20285-2006.
Top Appearance Quality Surface adopts technology without welding spots, so that to get smooth appearance.
Advanced Surface Treatment We introduce the process of heat transfer printing instead of traditional painting process to ensure the decorative and environment-friendly performance of rosewood steel fire door.
Top Flexibility All of our steel fire doors can smoothly open and close, definitely without the problem of jam or so.
Small Door Leaf Opening Force Door leaf opening force of our rosewood steel fire door is no more than 66N, which is much smaller than 80N according to GB12955-2008.
Customized Products Nearly all of our steel fire doors can be customized as your request.


Vision Panels


As far as vision panels are concerned, we provide you with different choices such as CCC certified fire resistant heat insulated glass which has a fire rate of up to 3 hours, 5mm thick UL-listed ceramic glass and 6mm thick boron glass.

The maximum glass area is 100 square meters. Inches per door leaf for 2 hours fire rated doors. When the fire rating longer than 2 hours, we don’t suggest vision panels in doors.

In addition, we provide reinforcement channel and glass frame made of 0.8mm thick galvanized steel.


UL Listed Gal. Steel 1 Hour Commercial Fire Rated Doors With Vision Panel 1



1. Matured packaging team consisting of professional and well-trained packaging staff with quality packaging materials.

2. Quick delivery within 35 days since transfer confirmed.
3. Reliable and professional logistics services which are all in long-term cooperation with us.
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.


Why Choose Us?


1. All of our fire doors are in top quality and at competitive prices.

2. Free pre-sales consult on any questions about fire doors.

3. Brand Advantage: We insist purchasing to be a reliable fire doors supplier for high-end real estate agents.

4. All fire doors can be customized as your request.

5. Good after-sale service.

More than 20 years experience in fire door industry.


UL Listed Gal. Steel 1 Hour Commercial Fire Rated Doors With Vision Panel 2
