Single Swing Right/Left Hand 60 min Beige Particle Board Wood Fire Door With Steel Frame
Contact Person : Zowor
Phone Number : +86-13393731249
|Minimum Order Quantity :||1 set||Price :||negotiable|
|Packaging Details :||Inside Bubble Bags+ Strong Carton+Wooden Frame||Delivery Time :||45 Days After Payment Received|
|Payment Terms :||western union, moneygram,cash, l/c, t/t||Supply Ability :||600 Sets per Day|
|Place of Origin:||CHINA||Brand Name:||ZHONGWO|
|Material:||Plywood||Infilling:||Fireproof Perlite Board|
|Thickness Of Door Leaf:||45 Mm||Frame Depth:||112/120 Mm|
|Thickness Of Steel Sheet For Door Frame:||1.2 Mm||Opening Force:||66 N|
|Opening Degree:||90-180 Degrees||Fire Rating:||30/60/90 Mins|
45 minute fire rated wood door,
timber fire doors
Single Swing Right Handed Solid Wood Internal Fire Doors 45mm Thick Perlite Board Infilling
Wood Fire Door with Steel Frame
Zhongwo fire door is a factory dedicated to producing and selling all kinds of fire rated doors such as steel fire door, wooden fire door, wooden fire door with steel frame and stainless steel fire door with different kinds of fire ratings varing from 30mins via 60mins to 90 and even 120mins.
Steel wooden fire doors are divided into two kinds, namely fire doors consisting of wood door leaf and steel frame and fire doors consisting of steel door leaf and wooden frames. By us we mean the forner one.
3. Hardware: Dorma fire lock from Germany, Quadruple hinges from Germany
|Product Name||Wooden Fire Door With Steel Frame|
|Fire Rating||30 min/60 min/ 90min/180 min|
|Certificate||CCC, ISO9001:2008; UL; BS|
|Material of Door Leaf||Galvanized Steel Sheet|
|Finish||Primer Painting, Laminating, Wood Veneer, Baking Paint|
|Infilling||Fireproof Perlite Board, Honeycomb Paper|
|Thickness of Door Leaf||
60min: 45 mm
60min: 112 mm
30min: 90 mm
|Open Style||Swing Open, Left Handed, Right Handed|
|Color||RAL Color as Customized|
Single Open: 24mmX 350mmX 600mm
Double Open: 32mmX 350mmX 600mm
Or customized As Request
|Fireproof Seal Strip||
60min: FPJ-A-15X 2
30min: FPJ-A-15X 2
|Hardware||High Quality Fire Lock, Fire Bolt, Fire Hinge, Fire Sequencer, Fir Door Closer and Others as Request|
Inside Bubble Bags with Strong Carton
|Delivery Time||45Days After Payment Received|
Frame Depth: 90/ 112/ 120mm
Thickness of Steel Sheet:1.2mm
Structure: Galvanized Steel Sheet+ Reinforcing Steel+Fireproof Perlite Board
Thickness of Reinforcing Steel: 3 mm
Density of Fireproof Perlite: 300±30kg/m3 ; 400±40kg/m3
Generally we provide UL listed hardware like fire door closer, fire hinges, fire locks. More options such as panic bars, electric-magnetic door holders and fire door selectors are also available.
Remarks: If you don’t want ironmongery from us but only need us to punch hardware insert holes, please send us the specification and drawings of hardware you need, it will be best if you send us delivery samples.
|Title||Step 1||Step 2||Step 3||Step 4|
|Door||PEP Paper around the door||Foam Channel Around 4 Edges and Corners||Foam Board on both sides on PEP Paper||
|Frame||PEP Paper around the frame||Tape Winding||Strong Carton|
|Besides, we also provide wooden pallet package as per your request.|
Why Choose Us?
1. All of our fire doors are in top quality and at competitive prices.
2. Free pre-sales consult on any questions about fire doors.
3. Brand Advantage: We insist purchasing to be a reliable fire doors supplier for high-end real estate agents.
4. All fire doors can be customized as your request.
5. Good after-sale service.
6. More than 20 years experience in fire door industry.
