Wood Grain Finish UL Listed Fire Safety Door With Glass Ceramic Cold Gray Color

Minimum Order Quantity : 1 set Price : Negotiable
Packaging Details : PEP Paper around the door+Foam Channel Around 4 Edges and Corners+Foam Board on both sides +Strong Carton Delivery Time : 45 Days After Payment Received
Payment Terms : western union, moneygram,cash, l/c, t/t Supply Ability : 600 Sets per Day
Place of Origin: CHINA Brand Name: ZHONGWO
Certification: BS, WHI, UL, CCC Model Number: ZW-SM09

Detail Information

Material: Galvanized Steel Fire Rating: Up To 180 Mins
Finish: Prime Paint, Powder Coating, Wood Grain Thickness Of Door Leaf: 45 Mm
Thickness Of Steel Sheet For Door Leaf: 0.8 Mm Thickness Of Steel Sheet For Door Frame: 1.2 Mm
Infilling: Perlite Board; Honeycomb Paper, Mgo Board Glass: 5 Mm Glass Ceramic
Weight: 35Kg/m2 Opening Type: Swing Open
High Light:

fire proof door

,

fire protection door

Product Description

Wood Grain Finish UL Listed Fire Safety Door With Glass Ceramic Cold Gray Color



FUL Steel Fire Door



Zhongwo Fire Door began its work in 1995 as a rural workshop of only 15 people. Over the past 24 years, we have grown to 2 production bases with a total area of over 89,000 m2 and a modern group company with more than 400 employees. Thanks to our state-of-the-art full-time production line, we can produce one door in 1 minute, so our daily output is 1,000 doors.



When it comes to steel fire doors, we have different standards that meet the different needs of buyers from different countries.

Standard of UL listed fire doors: UL10 (b), UL10 (c), NFPA252, CAN / ULC S104;

Standard of BS steel fire doors: BS476: 22;



Our UL listed steel fire door holds up to 180mins against fire. Key materials of UL listed steel fire doors are galvanized steel and Mgo plate as filler. For gal. steel face panel, we have three options: 0.8mm, 1.0mm and 1.5mm. For filler, we also provide perlite boards and honeycomb paper for your choice.



Material of frame remains galvanized steel, thickness is 1.2mm, 1.5mm and 2.0mm.



UL steel fire door thickness is generally 45 mm, frame depth 115 mm.



Wood Grain Finish UL Listed Fire Safety Door With Glass Ceramic Cold Gray Color 0



The types of doors differ in two standard series, namely doors and doors flowing with vision panels. We can also customize different types as per your request.



Our dimensions are standard 6 'x 7 & max. 8 'x 8' for double doors and standard 3 'x 7' and max. 4’X8 for single doors. Attention, here we mean the structural opening sizes. If you only need doors, please inform us of that.



For surface finish, we have powder coating, wood grain and PVC coating for your choice. The color scheme from us is RAL.



Reinforcements

  • 3mm thick steel plate on sides of hinges, closer and locks.
  • Double U-Type channel made of 1.2 mm thick galvanized steel sheet
  • Doors shall be reinforced for all types of surface devices. Drilling and tapping of surface devices to be performed in this area by the erector.
  • The edges of the doors shall be continuously welded and in contact with the floor to ensure their final feel.

Vision Panels

We provide you with a range of different bottles such as CCC certified fire resistant heat resistant glass which has a fire rate of up to 3 hours, a list of 5mm thick UL-listed ceramic glass and 6mm thick boron glass.

The maximum glass area is 100 square meters. Inches per door leaf for 2 hours fire rated doors. When the fire rating longer than 2 hours, we don’t suggest vision panels in doors.

In addition, we provide reinforcement channel and glass frame made of 0.8mm thick galvanized steel.



Hardware

Generally we provide UL listed hardware like fire door closer, fire hinges, fire locks. More options such as panic bars, electric-magnetic door holders and fire door selectors are also available.

Remarks: If you don’t want ironmongery from us but only need us to punch hardware insert holes, please send us the specification and drawings of hardware you need, it will be best if you send us delivery samples.



Wood Grain Finish UL Listed Fire Safety Door With Glass Ceramic Cold Gray Color 1



Package

Title Step 1 Step 2 Step 3 Step 4
Door PEP Paper around the door Foam Channel Around 4 Edges and Corners Foam Board on both sides on PEP Paper

Strong Carton



Frame PEP Paper around the frame Tape Winding Strong Carton
Besides, we also provide wooden pallet package as per your request.
