Zowor Certified 3 Hour Fire Rated Steel Door Soundproof Commercial Hollow Metal Fireproof Lab Cleanroom Hospital 36x84 Modern
Contact Person : lan
Phone Number : 176 3354 0888
| Minimum Order Quantity : | 1 set | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Inside Bubble Bags+ Strong Carton+Wooden Frame | Delivery Time : | 35 Days After Payment Received |
| Payment Terms : | western union, ,cash, l/c, t/t | Supply Ability : | 600 Sets per Day |
| Place of Origin: | CHINA | Brand Name: | ZHONGWO |
|---|---|---|---|
| Certification: | BS， WHI， UL, CCC |
|
Detail Information |
|||
| Product Name: | 1 Hour Rated Gal. Steel Insulated Fire Door For Commercial Buildings/ Powder Coated Finish | Fire Rating: | 90 Mins |
|---|---|---|---|
| Thickness Of Door Leaf: | 55 Mm | Thickness Of Door Leaf Steel Sheet: | 0.8mm |
| Thickness Of Door Frame Steel Sheet: | 1.2mm | Surface Treatment: | Wood Grain; Powder Coating |
| Material: | Galvanized Steel | Open Direction: | Outwards |
| Size: | Customized | Color: | Choice Available |
Product Description
Safety is the precondition for efficient work.
The boiler is an important heat supply equipment in industrial and civil heating, which indicates the significance of fire safety in boiler rooms. To ensure safety of boiler rooms it is widely asked worldwide that man must equip boiler rooms with best quality fire doors.
Zhongwo external insulated fire doors consist of door leaf and door frame both made from galvanized steel. Inside there are fireproof perlite board of no thinner than 53 mm and with density of more than 420±40kg/m3. And the appearances can match nearly any tone of the entire boiler rooms because of her powder coating surface treatment with optional colors. And the CCC certification indicates its fire duration to be at least 90 minutes. What’s more, we invent a kind of gap covering board which can avoid the spread of flame and smoke to the utmost extent.
Specification
| Product Name | Steel External Insulated Fire Door |
| Certificate | CCC, ISO9001:2008,BS,UL |
| Material | Galvanized Steel |
| Open Style | Swing Open |
| Surface Treatment | Powder Coating |
| Color | Milky White, Matte Orange, Dark Gray, Cold Gray White or as Request |
| Fireproof Seal Strip | FPJ-B-15X 2 |
| Hardware | 1 Pipe Lock, 6 Fire Hinges, 2 Fire Bolts, Fire Door Closer both of Chinese or International Top Brand |
| Package | Inside Bubble Bags with Outside Wooden Frame |
| Delivery Time | 35Days After Payment Received |
| Shipping Port | Qingdao |
Remark: We can also insert vision panels or skylights as your request.
Door Frame:
Frame Depth: 120mm
Thickness of Steel Sheet:1.2mm
Structure: Galvanized Steel Sheet+Fireproof Perlite Board+Reinforcing Steel Sheet+Galvanized Steel Sheet
Thickness of Reinforcing Steel Sheet: 3 mm
Density of Fireproof Perlite: 420±40kg/m3
Weight: 25kg/m2
Door Leaf:
Thickness:55mm
Thickness of Steel Sheet: 0.8mm
Structure: Galvanized Steel Sheet+Fireproof Perlite Board+Galvanized Steel Sheet
Density of Fireproof Perlite Board: 420±40kg/m3
Thickness of Frieproof Perlite Board: 53mm
Gap Covering Steel Sheet: 0.8 mm Galvanized Steel Sheet
Reinforcing Skeleton: 1. At the Lock: Type C 48mm X 16mm & Type C 44mm X 16mm; 2. At the upper and bottom hinges: Type C 48mm X 16mm
Weight: 25kg/m2
Why Choose Us?
1. All of our fire doors are in top quality and at competitive prices.
2. Free pre-sales consult on any questions about fire doors.
3. Brand Advantage: We insist purchasing to be a reliable fire doors supplier for high-end real estate agents.
4. All fire doors can be customized as your request.
5. Good after-sale service.
6. More than 20 years experience in fire door industry.
